Offline AOI Machine

Dimension:940*950*1280 mm
PCB width:0-350(mm)
Inspection Component: 0402 chip
Weight:Aprox. 450kg
Product description: Offline AOI Machine, Dimension:940*950*1280 mm, PCB width:0-350(mm), Inspection Component: 0402 chip, Weight:Aprox. 450kg
INQUIRY

Offline AOI Machine

Specifications:

Inspection System & Optical System

Inspection Object	Skew / Tombstone / Wrong part / Missing / Overturning / Damaged / Cold joint / insufficient solder / Excess solder
Inspection Component	0402 chip , IC pin(0.3mm pitch), wave solder
Inspection Method	Full color image statistic analysis, OCP, IC bridge analysis, color linear analysis color non-linear analysis, similarity analysis, black-white ratio analysis, intensity analysis
Camera	Color CCD (1.45MPa Pixels), Resolution 20um, FOV 20*20mm (customized), speed?2000mm²/s
Light Source	RGB Ring Multi-angle LED combination lighting, high brightness, standard CCTV lens, DOV 2mm

Software & Computer

Computer

CPU: Dual-core 2.7G, RAM: DDRIII-2G hard disk : 500G, 22" wide screen LCD

Mechanical System

PCB Thickness	0.3 - 5.0 (PCB Warpage < 5mm)
PCB Width	30-380mm (can be customized)
Driving Method	AC Servo Motor+ball screw rod+linear guide rail
Motion Speed	Max 700mm/s
PCB Clamp	Automatic
Power	AC220V / 50Hz, UPS 1000W
Dimension	9409501280 mm
Weight	Aprox. 450kg
